JS6960GHCP Nature Gas City Bus
Model:JS6960GHCP
Dimensions：9545×2500×3430
Number of seats/Capacity：28+2+1/29(7250mm)
Maximum gradeability：20%
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Details
Main parameters and configuration of JS6960GHCP Natural gas city
| Model | JS6960GHCP |
| Dimensions(mm) | 9545×2500×3430 |
| Number of seats/Capacity | 28+2+1/29(7250mm) |
| Maximum gradeability | 20% |
| Approach/departure angle | 8/7° |
| Engine | PWeichai WP7NG210E51 (155KW, 850N.M, CNG, Euro 5) |
| Maximum speed | 80 |
| Axles | 5T disc front axle,10T drum rear axle |
| Suspension system | Multi-leaf spring 8/11, front and rear lateral stabilizer bars, leaf spring main board with additional anti-friction plate |
| Tires | 10R22.5 tubeless radial tire (vacuum tire) |
| Steering system | Integral power steering |
| Braking system | Front disc and rear drum brakes, pneumatic dual-circuit service brakes, energy storage spring parking brakes, drum axle with automatic adjustment arms |
| Body structure | Semi-loaded frame |
| Interior | Formed air duct, equipped with ordinary interior ceiling lights, a wheelchair area, handrails, guardrails, advertising rings |
| Seats | 28 bus seats, high back mechanical shock absorbing adjustable driver seat |
| Air conditioning&heater | Roof mounted non-independent air conditioner, water heating defroster |
| Doors and windows | Front single center double inward swing pneumatic passenger door, aluminum frame sliding window, one manual half-width sunshade on the front windshield, retractable driver's side sunshade |
| Destination sign | Front and rear LED electronic road signs |
| Rear view system | Color monitor |
| Floor | Two-step |
| Others | MP3 radio, passenger counting system, billboard hanging ring, cabin temperature alarm system |
