JS6851GH
The side wall is built by rolling skin tensile structure ,treated by phosphating process,and with fine coating process,the bus has good performance of anticorrosion and longer service life.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
| Model | JS6851GHP |
| Dimension(mm) | 8540*2400*3030 |
| G.V.W(kg) | - |
| Max. speed(km/h) | 69 |
| Engine | WP5.180E51 |
| Body structure | High-strength rectangular tube skeleton |
| Clutch | φ395 diaphragm spring clutch |
| Gearbox | 5-speed manual gearbox |
| Brake system | Dual circuit pneumatic brake, energy storage spring parking brake, ABS |
| Suspension system | Leaf spring suspension with stabilizer bar |
| Tire | 9R22.5 |
| Fuel tank (L) | 140 |
| Seats | 21+1 |
| Interiors | Integrated inner trimming, curtain, lights |
| Air conditioner (A/C) | Non-independent roof-mounted A/C (14000kcal) |
| Heating system | - |
| Audio & video system | e-clock |
| vehicle emissions (L) | 4.1 |
| rated power/rotational speed （kW/rpm） | 115/2600 |
| Max. torque/rotational speed （N.m/rpm） | 520/1200～1800 |
Medium-sized city bus
Huge side window and front window improve the transparency of the bus.The new frame structure,reduces the steps inside the bus,and the interior layout is elaborately designd,raising the comfortability of seating.The side wall is built by rolling skin tensile structure ,treated by phosphating process,and with fine coating process,the bus has good performance of anticorrosion and longer service life.
Asiastar starbus family is always with European city bus noble ancestry, simple lines, sharp but steady. It has advanced configuration, humanistic facilities, and high economic cost. The vehicle is strong and light, and can be equipped with Weichai engines, green environmental protection. the family members have the various versions of high floor, lower entrance ,lower floor , two doors, three doors for passenger, left hand and right hand driving.
